I. Product features
1,Adhesive installation design
n Symmetrical industrial shape design, exquisite and compact
n Good ventilation and heat dissipation channels
n Integrated built-in forward-facing Camera design
Automotive-grade reliability interface
2,Powerful coding + computing power + reliability
n H.265/264,Dual-core 1.3GHZ
n Innovative process technology, good power consumption
n Integrated powerful arithmetic unit
n Support ADAS/DMS/BSD.
Extremely strong high and low temperature survival environment
3,Many functional interfaces
n 4 Channels AHD 1080P/720P
n Single TF card storage
n GPS,4G,WiFi/BT
n 2* Serial port
n 4*IO Input+1*IO Output
n Built-in MIC and speaker, support voice intercom
n Built-in super capacitor, extremely strong data security protection
CMS fleet management platform online monitoring
Playback Mobile DVR 1080P HD Image quality
|
Device Model |
M515 |
|
Operating System |
Liunx3.10 |
|
Language |
Chinese / English |
|
Hardware Platform |
FH |
|
Video Encoding |
H.265/H.264 compatible |
|
Audio Coding |
G.711A |
|
Gravity Sensor |
3 Axis Gyroscope |
|
Position |
Support GPS/BD dual mode, optional support for high-precision positioning |
|
Mobile Network Standard |
4G full Netcom |
|
WIFI |
Optional, support built-in WIFI module, 2.4G 802.11b/g/n |
|
Video Input |
4-channels AHD1080P/720P |
|
Video Output |
1-channel CVBS HD output |
|
Audio Input |
4-channels Input |
|
Audio Output |
1-channel Output |
|
Storage |
TF*1,Support 512GB |
|
Antenna |
4G antenna built-in |
|
|
External Gmouse positioning antenna |
|
|
Optional, built-in WIFI |
|
VOIP Intercom |
Support |
|
Switching Volume |
4-channels inputs / 1-channel output |
|
Power Consumption |
Less than 3W (no peripherals) |
|
Input Power |
Wide power supply design, support AC/DC9~36V |
|
Dimension |
90mm*90mm*30mm(L×W×H) |
|
Weight |
Net weight of host 295g |
|
Resolution |
AHD 1080P |
|
Minimum Illumination |
0.05Lux |
|
Lens |
2.1MM |
|
Angle |
120° horizontal |
Delivery time:
sample order: 2-5 working days
10-100 kits: 7-10 working days
100-1000 kits: 15-20 working days
What is Warranty time and repairing service?
A: Warranty: 1 year
Life time maintenance and repairing service
We will continue to provide technical support and repairing service after warranty period.
